| Brand Name : | BULLDOG,NICEPARTS |
| Model Number : | Atlas Copco SB152 |
| Price : | Consultation by letter |
| Payment Terms : | T/T, Western Union, MoneyGram,Paypal,Alipay |
| Supply Ability : | 100set |
| Delivery Time : | 3-10 Days After Payment received |
Model:Atlas Copco SB152 Hydraulic breaker Repair service seal kit
Part Name:Hydraulic breaker seal kit, Hydraulic hammer seal kit
Tool:50MM
Part Number:3315 2905 90
Material:TPU+HNBR+PTFE
Packaging Details: bag or box +carton
CertifiCATEEion: IOS 9001
Delivery Time: 2-5days upon payments confirmed
Position:Atlas Copco Hydraulic Breaker Systerm
Brand:BULLDOG,OEM or as Required
Payment Terms: TT/Paypal/WEST UNION
Supply Ability: 500
MOQ:1set
Parts list
| NO. | product name | Quantity | Part number |
| 1 | Breaker body | 1 | - |
| 2(3-5) | Bushing, complete | 1 | 3315 3539 80 |
| 3 | Bushing | 1 | - |
| 4 | Scraper ring | 1 | 3315 3564 00 |
| 5 | O-ring | 4 | 0663 2102 89 |
| 6 | Stop ring | 1 | 3315 2918 00 |
| 7 | Plug | 1 | 0686 1000 09 |
| 8 | Hexagon socket plug | 6 | 0686 6442 07 |
| 9 | Water nozzle, option | 1 | 3315 3952 00 |
| 10 | Lock pin | 1 | 3315 2930 00 |
| 11 | Spring pin, option | 1 | 0108 1691 26 |
| 12 | Tool retainer | 2 | 3315 1470 00 |
| 13 | Lock buffer | 1 | 3315 1419 00 |
| 14 | Hexagon socket plug | 4 | 0686 3718 01 |
| 15 | Coil spring | 1 | 3315 2933 00 |
| 16 | Diaphragm support | 1 | 3315 2889 00 |
| 17 | Diaphragm | 1 | 3315 2890 00 |
| 18 | Accumulator house | 1 | 3315 2824 00 |
| 19 | Hexagon socket screw | 8 | 0211 1965 34 |
| 20 | Hexagon socket plug | 1 | 0686 3718 05 |
| 21 | Seal ring | 1 | 3115 3290 02 |
| 22 | O-ring | 1 | 0663 2120 00 |
| 23 | Charge valve | 1 | 3315 3660 00 |
| 24 | O-ring | 1 | 0663 2114 00 |
| 25 | Parallel pin | 1 | 0101 4140 00 |
| 26(27-29) | Nipple, complete | 1 | 0570 7000 03 |
| 27 | Nipple | 1 | - |
| 28 | Seal ring | 1 | 0664 0000 03 |
| 29 | O-ring | 1 | 0663 9055 01 |
| 30 | Cap | 2 | 0570 7000 19 |
| 31 | Valve cover | 1 | 3315 3640 00 |
| 32 | O-ring | 2 | 0663 2114 90 |
| 33 | Control valve | 1 | 3315 2919 00 |
| 34 | Seal ring | 2 | 0665 0900 14 |
| 35 | Plug | 1 | 3315 3050 00 |
| 36(37-39) | Pressure relief valve, complete | 1 | 3315 3350 00 |
| 37 | Pressure relief valve | 1 | - |
| 38 | O-ring | 1 | 0663 9032 01 |
| 39 | O-ring | 1 | 0663 9054 01 |
| 40(41-43) | Restrictor standard, complete | 1 | 3315 3695 51 |
| 41 | O-ring | 1 | 0663 9054 01 |
| 42 | O-ring | 1 | 0663 9032 01 |
| 43 | Restrictor | 1 | - |
| 44 | Grease nipple | 1 | 0544 2153 00 |
| 45 | Wiper | 1 | 0665 9099 54 |
| 46 | Piston rod seal | 1 | 0665 0701 31 |
| 47 | O-ring | 5 | 0663 2114 56 |
| 48 | O-ring | 1 | 0663 2106 31 |
| 49 | Liner | 1 | 3315 2913 00 |
| 50 | O-ring | 4 | 0663 2100 53 |
| 51 | Piston | 1 | 3315 2917 00 |
| 52 | Piston rod seal | 1 | 0665 0701 32 |
| 53 | Back head | 1 | 3315 2939 00 |
| 54(55-56) | Check valve, complete | 1 | 3315 2448 81 |
| 55 | Check valve | 1 | - |
| 56 | Valve rubber | 1 | 3315 2808 00 |
| 57 | Hexagon head screw | 8 | 0147 1481 03 |
| 58 | Base plate, option | 1 | 3315 3043 00 |
| 59(60-61) | Set of eight screws, complete | 1 | 3315 2964 90 |
| 60 | Screw | 8 | - |
| 61 | Nut | 8 | - |
Parts exploded view
